A bucket elevator head pulley is installed at the upper head of a bucket elevator. It guides the belt or chain around the top drum and helps the buckets discharge material into the outlet. This part works in a small space but carries high pulling force, so the shaft, shell, hub, and bearing position must be matched carefully.
The bucket elevator head pulley is used in vertical lifting systems for cement, grain, fertilizer, sand, mineral powder, and other granular or powdered materials. A smooth and balanced pulley helps the elevator run with less vibration, while the right surface treatment can reduce belt slip. When this product is used in dusty places, sealed bearings and a clear guard design make inspection easier. The pulley size can be changed according to bucket width, elevator height, belt tension, and motor power.
Product Parameters
|
Parameter |
Value |
|
Main Material |
Carbon steel drum and machined steel shaft |
|
Surface |
Plain steel, rubber lagging, or other selected coating |
|
Bearing Position |
External or internal bearing layout according to elevator design |
|
Pulley Size |
Made according to bucket width and lifting load |
|
Shaft End |
Custom keyway, step, or thread if required |
|
Balance |
Checked before packing for smoother rotation |
|
Application |
Bucket elevator top head section |
|
Finish |
Painted, galvanized, or agreed anti-rust finish |
Product Advantages
1. For bucket elevator head pulley, supports stable discharge at the elevator head.
2. Can be matched with belt or chain elevator structures.
3. Suitable for replacement when old pulley data is clear.
Main Applications
1. Grain and feed bucket elevators.
2. Cement, lime, and mineral powder lifting systems.
3. Fertilizer, sand, and small bulk material handling lines.
