The troughing roller is produced for bulk material conveyors used in mines, sand plants, cement lines, ports and storage yards. The roller shell is normally made from steel pipe, with sealed bearings pressed into both ends and a straight shaft running through the center.
Product Parameters
|
Parameter |
Value |
Notes |
|
Roller diameter |
89/108/133/159 mm |
Project selection |
|
Trough angle |
20°/35°/45° |
Common conveying angles |
|
Roller length |
250-530 mm each |
For 3-roller set |
|
Shaft diameter |
20/25/30 mm |
By load requirement |
|
Bearing |
6204/6205/6305 |
Sealed type |
|
Frame |
Q235 steel bracket |
Matched with belt width |
Our Services
We provide drawing checking, roller length confirmation, bearing option discussion, packing by size and after-sales communication for replacement orders. For repeat users, we also keep basic size records so the next order can move faster.
FAQ
Q: Can the troughing roller be made according to an old sample?
A: Yes. Roller diameter, shaft length, bearing model and end structure can be checked from a sample or drawing.
Q: What information is needed for quotation?
A: Belt width, roller length, diameter, shaft diameter, bearing type and required quantity are enough for a basic quote.
Q: Can rubber ring or galvanized surface be supplied?
A: Yes. These options are usually selected for wet, sticky or outdoor conveying sites.
